Sita Attika Stainless Steel 87.5 Degree Pipe Bend, with Seal made of EPDM, pipe lengths from 500mm up to 5000mm, with sizes from 50mm up to 160mm.
Made of stainless steel to DIN EN 1124-1/2. Plug-in pipe system with a seal made of EPDM mounted in the socket at the factory. Sharp end with a 20° phase to simplify assembly. Pipes and shaped parts completely dip treated to ensure a smooth matt silver surface.
Up to DN 125, the wall thickness is 1 mm, for DN 150 the wall thickness is 1.25 mm.
Manufacturer; Sita
Product Code: 70048850/70048875/70048811/70048812/70048816
